Migrando VM'S do ODA/OVM para ODA/KVM
No post anterior aqui, abordamos sobre como configurar e gerenciar o KVM nas novas versões do ODA.
Agora, vamos falar um pouco sobre a migração de maquinas virtuais.
Como todos já sabem, a outra plataforma conhecida como “OVM” é baseada no Hypervisor XEN. E a grande pergunta que fica é … Como migrar as maquinas virtuais do “OVM” para o “KVM” ?
É isso meus amigos que vamos abordar neste artigo.
De forma bem simplificada e direta vamos aos detalhes da maquina virtual que vamos migrar do OVM para o KVM.
[root@odax5node1 ~]# oakcli show vm MVPEP-SML-TRN
The Resource is : MVPEP-SML-TRN
AutoStart : restore
CPUPriority : 100
Disks : |file:/OVS/Repositories/repo1/.ACFS
/snaps/MVPEP-SML-TRN/VirtualMachine
s/MVPEP-SML-TRN/7396bcf1382c42b1bf4
31ece9bcc23ee.img,xvda,w||,xvdb:/OV
S/Repositories/repo1/.ACFS/snaps/MV
PEP-SML-TRN/VirtualMachines/MVPEP-S
ML-TRN/cdrom,r|
Domain : XEN_PVM
DriverDomain : False
ExpectedState : online
FailOver : true
IsSharedRepo : true
Keyboard : en-us
MaxMemory : 32768M
MaxVcpu : 24
Memory : 32768M
Mouse : OS_DEFAULT
Name : MVPEP-SML-TRN
Networks : |bridge=net1|
NodeNumStart : 1
OS : OL_5
PrefNodeNum : 1
PrivateIP : None
ProcessorCap : 0
RepoName : repo1
State : Online
TemplateName : otml_oraclelinux610
VDisks : |oakvdk_disk120_mvpep-sml-trn_repo1
|
Vcpu : 24
cpupool : default-unpinned-pool
vncport : 5901
[root@odax5node1 ~]# oakcli show vdisk disk120_mvpep-sml-trn -repo repo1
The Resource is : disk120_mvpep-sml-trn_repo1
Name : disk120_mvpep-sml-trn_repo1
RepoName : repo1
Size : 120G
Type : shared
VmAttached : 1
A parte que nos interessa é literalmente esta:
Disco de Boot /OVS/Repositories/repo1/.ACFS/snaps/MVPEP-SML-TRN/VirtualMachines/MVPEP-SML-TRN/7396bcf1382c42b1bf431ece9bcc23ee.img Disco Secundario anexado /OVS/Repositories/repo1/.ACFS/snaps/oakvdk_disk120_mvpep-sml-trn/VirtualDisks/oakvdk_disk120_mvpep-sml-trn
[root@odax5node1 MVPEP-SML-TRN]# oakcli show repo repo1 -node 0
The Resource is : repo1_0
AutoStart : restore
DG : DATA
Device : /dev/asm/repo1-341
ExpectedState : Online
FreeSpace : 236025.2M
MountPoint : /u01/app/sharedrepo/repo1
Name : repo1_0
PFreeSpace : 28.81%
RepoType : shared
Size : 819200.0M
State : Online
Version : 2
Até aqui tudo certo, temos todas as informações da VM.
Agora vamos para parte de “backup”
[root@odax5node1 MVPEP-SML-TRN]# oakcli stop vm MVPEP-SML-TRN
Maquina parada vamos copiar discos.
[root@odax5node1 MVPEP-SML-TRN]# cd /u01/app/sharedrepo/repo1
[root@odax5node1 repo1]# cp .ACFS/snaps/MVPEP-SML-TRN/VirtualMachines/MVPEP-SML-TRN/7396bcf1382c42b1bf431ece9bcc23ee.img /backup/
[root@odax5node1 repo1]# cp .ACFS/snaps/oakvdk_disk120_mvpep-sml-trn/VirtualDisks/oakvdk_disk120_mvpep-sml-trn /backup/
Copia finalizada, vamos sair do X5 “OVM” e vamos para o X8 KVM. OBS: Não copie nenhum arquivo para o VMSTORAGE/REPOSITORIO, neste local apenas arquivos das VM'S.
[root@odax8godata ovmstorage]# cd /backup
[root@odax8godata backup]# ll -rths
total 241G
121G -rw------- 1 root root 120G Feb 12 13:08 7396bcf1382c42b1bf431ece9bcc23ee.img
121G -rw-r--r-- 1 root root 120G Feb 12 13:56 oakvdk_disk120_mvpep-sml-trn
64K drwx------ 2 root root 64K Feb 18 00:56 lost+found
52K drwxr-xr-x 4 root root 20K Feb 18 19:24 old
[root@odax8godata backup]# qemu-img info 7396bcf1382c42b1bf431ece9bcc23ee.img
image: 7396bcf1382c42b1bf431ece9bcc23ee.img
file format: raw
virtual size: 120G (128849018880 bytes)
disk size: 120G
[root@odax8godata backup]# qemu-img info oakvdk_disk120_mvpep-sml-trn
image: oakvdk_disk120_mvpep-sml-trn
file format: raw
virtual size: 120G (128849018880 bytes)
disk size: 120G
Agora vamos renomear os discos para ficar mais fácil a compreensão.
[root@odax8godata backup]# mv 7396bcf1382c42b1bf431ece9bcc23ee.img DISCO_DE_BOOT.ovm
[root@odax8godata backup]# mv oakvdk_disk120_mvpep-sml-trn DISCO_SECUNDARIO.ovm
[root@odax8godata backup]# ll -rths
total 241G
121G -rw------- 1 root root 120G Feb 12 13:08 DISCO_DE_BOOT.ovm
121G -rw-r--r-- 1 root root 120G Feb 12 13:56 DISCO_SECUNDARIO.ovm
64K drwx------ 2 root root 64K Feb 18 00:56 lost+found
52K drwxr-xr-x 4 root root 20K Feb 18 19:24 old
[root@odax8godata backup]# qemu-img info DISCO_DE_BOOT.ovm
image: DISCO_DE_BOOT.ovm
file format: raw
virtual size: 120G (128849018880 bytes)
disk size: 120G
[root@odax8godata backup]# qemu-img info DISCO_SECUNDARIO.ovm
image: DISCO_SECUNDARIO.ovm
file format: raw
virtual size: 120G (128849018880 bytes)
disk size: 120G
Pronto, temos algumas informações relevantes sobre os discos, agora vamos iniciar a conversão do disco de OVM/XEN para KVM.
Antes de iniciar, precisamos saber pra qual tipo de disco vamos converter e quais são as propriedades do mesmo, para saber isso peguei informações de um disco já existente que foi criando de forma nativa pelo ODACLI.
[root@odax8godata vm_MACHINE19C]# qemu-img info MACHINE19C
image: MACHINE19C
file format: qcow2
virtual size: 200G (214748364800 bytes)
disk size: 16G
cluster_size: 65536
Format specific information:
compat: 1.1
lazy refcounts: true
refcount bits: 16
corrupt: false
[root@odax8godata vdisk_VDISK1]# qemu-img info VDISK1
image: VDISK1
file format: raw
virtual size: 300G (322122547200 bytes)
disk size: 300G
Aqui identificamos que não precisaremos converter o disco secundario ou seja o VDISK, vamos precisar converter apenas o disco de boot.
Tendo em mãos todas as informações necessarias vamos iniciar a conversão dos discos (OBS: NUNCA FAÇA ISSO DIRETAMENTE COM O DISCO DA MAQUINA VIRTUAL DO OVM/XEN, SEMPRE EXECUTE ISSO COM UM BACKUP DO DISCO/VM).
[root@odax8godata backup]# qemu-img convert -p -f raw -O qcow2 -o lazy_refcounts=on DISCO_DE_BOOT.ovm DISCO_DE_BOOT.qcow2
(100.00/100%)
[root@odax8godata backup]# ll -rths
total 355G
121G -rw------- 1 root root 120G Feb 12 13:08 DISCO_DE_BOOT.ovm
121G -rw-r–r-- 1 root root 120G Feb 12 13:56 DISCO_SECUNDARIO.ovm
64K drwx------ 2 root root 64K Feb 18 00:56 lost+found
52K drwxr-xr-x 4 root root 20K Feb 18 19:24 old
112G -rw-r–r-- 1 root root 112G Feb 18 19:43 DISCO_DE_BOOT.qcow2
[root@odax8godata backup]# qemu-img info DISCO_DE_BOOT.qcow2
image: DISCO_DE_BOOT.qcow2
file format: qcow2
virtual size: 120G (128849018880 bytes)
disk size: 112G
cluster_size: 65536
Format specific information:
compat: 1.1
lazy refcounts: true
refcount bits: 16
corrupt: false
[root@odax8godata backup]# qemu-img info DISCO_SECUNDARIO.ovm
image: DISCO_SECUNDARIO.ovm
file format: raw
virtual size: 120G (128849018880 bytes)
disk size: 120G
Disco convertido vamos iniciar a criação da VM.
Primeiro vamos criar um vdisk de 120GB (O tamanho tem quer ser exatamente o mesmo do disco/OVM). Esse disco será substituído pelo “DISCO_SECUNDARIO.img”
[root@odax8godata vdisk_VDISK1]# odacli create-vdisk -n DISCO_SECUNDARIO -sh -s 120G -vms OVMSTORAGE
Job details
----------------------------------------------------------------
ID: db9330e0-a124-49f0-9ffd-5b92e868c8d5
Description: VM disk DISCO_SECUNDARIO creation
Status: Created
Created: February 20, 2021 2:12:38 AM BRT
Message:
Task Name Start Time End Time Status
---------------------------------------- ----------------------------------- ----------------------------------- ----------
[root@odax8godata ~]# cd /u05/app/sharedrepo/ovmstorage/.ACFS/snaps/vdisk_DISCO_SECUNDARIO
[root@odax8godata vdisk_DISCO_SECUNDARIO]# ll -h
total 120G
-rw-r--r-- 1 root root 120G Feb 20 02:15 DISCO_SECUNDARIO
[root@odax8godata vdisk_DISCO_SECUNDARIO]# odacli create-vm -n MVPEP-SML-TRN -cp POOL12CORES -vc 24 -m 32G -vms OVMSTORAGE -s 120G -vd DISCO_SECUNDARIO -vn VNET1 -src /u01/V1003434-01.iso
Job details
----------------------------------------------------------------
ID: 6d3e30a1-ac79-485c-b29f-00a9ddbbc22f
Description: VM MVPEP-SML-TRN creation
Status: Created
Created: February 20, 2021 2:28:48 AM BRT
Message:
Task Name Start Time End Time Status
---------------------------------------- ----------------------------------- ----------------------------------- ----------
[root@odax8godata vdisk_DISCO_SECUNDARIO]# odacli list-vms
Name VM Storage Node Current State Target State Created Updated
-------------------- -------------------- --------------- --------------- --------------- ----------------------- -----------------------
MVPEP-SML-TRN OVMSTORAGE odax8godata ONLINE ONLINE 2021-02-20 02:28:59 BRT 2021-02-20 02:28:59 BRT
[root@odax8godata vdisk_DISCO_SECUNDARIO]# odacli describe-vm -n MVPEP-SML-TRN
VM details
--------------------------------------------------------------------------------
ID: f18f916b-19ae-4bfd-af33-f4a49f67f625
Name: MVPEP-SML-TRN
Created: 2021-02-20 02:28:59 BRT
Updated: 2021-02-20 02:28:59 BRT
VM Storage: OVMSTORAGE
Description: NONE
VM size: 120.00 GB
Source: V1003434-01.iso
OS Type: NONE
OS Variant: NONE
Graphics settings: vnc,listen=0.0.0.0
Display Port: :0
Status
--------------------------
Current node: odax8godata
Current state: ONLINE
Target state: ONLINE
Parameters
--------------------------
Preferred node: NONE
Boot option: NONE
Auto start: YES
Fail over: NO
Config Live
------------------------- -------------------------
Memory: 32.00 GB 32.00 GB
Max Memory: 32.00 GB 32.00 GB
vCPU count: 24 24
Max vCPU count: 24 24
CPU Pool: POOL12CORES POOL12CORES
Effective CPU set: 16-27,48-59 16-27,48-59
vCPUs: 0:16-27,48-59 0:16-27,48-59
1:16-27,48-59 1:16-27,48-59
2:16-27,48-59 2:16-27,48-59
3:16-27,48-59 3:16-27,48-59
4:16-27,48-59 4:16-27,48-59
5:16-27,48-59 5:16-27,48-59
6:16-27,48-59 6:16-27,48-59
7:16-27,48-59 7:16-27,48-59
8:16-27,48-59 8:16-27,48-59
9:16-27,48-59 9:16-27,48-59
10:16-27,48-59 10:16-27,48-59
11:16-27,48-59 11:16-27,48-59
12:16-27,48-59 12:16-27,48-59
13:16-27,48-59 13:16-27,48-59
14:16-27,48-59 14:16-27,48-59
15:16-27,48-59 15:16-27,48-59
16:16-27,48-59 16:16-27,48-59
17:16-27,48-59 17:16-27,48-59
18:16-27,48-59 18:16-27,48-59
19:16-27,48-59 19:16-27,48-59
20:16-27,48-59 20:16-27,48-59
21:16-27,48-59 21:16-27,48-59
22:16-27,48-59 22:16-27,48-59
23:16-27,48-59 23:16-27,48-59
vDisks: DISCO_SECUNDARIO:vdb DISCO_SECUNDARIO:vdb
vNetworks: VNET1:52:54:00:68:26:a9 VNET1:52:54:00:68:26:a9
Maquina criada, vamos para-la, para substituir pelos disco convertido.
[root@odax8godata vdisk_DISCO_SECUNDARIO]# odacli stop-vm -n MVPEP-SML-TRN
Job details
----------------------------------------------------------------
ID: e318afa6-9190-41e2-8167-d2f24a165928
Description: VM MVPEP-SML-TRN stop
Status: Success
Created: February 20, 2021 2:30:58 AM BRT
Message:
Task Name Start Time End Time Status
---------------------------------------- ----------------------------------- ----------------------------------- ----------
Validate dependency resources February 20, 2021 2:30:58 AM BRT February 20, 2021 2:30:58 AM BRT Success
Stop VM February 20, 2021 2:30:58 AM BRT February 20, 2021 2:31:03 AM BRT Success
[root@odax8godata vdisk_DISCO_SECUNDARIO]# odacli list-vms
Name VM Storage Node Current State Target State Created Updated
-------------------- -------------------- --------------- --------------- --------------- ----------------------- -----------------------
MVPEP-SML-TRN OVMSTORAGE OFFLINE OFFLINE 2021-02-20 02:28:59 BRT 2021-02-20 02:28:59 BRT
[root@odax8godata backup]# cd /backup/
[root@odax8godata backup]# ll -h
total 352G
-rw------- 1 root root 120G Feb 12 13:08 DISCO_DE_BOOT.ovm
-rw-r--r-- 1 root root 112G Feb 18 19:43 DISCO_DE_BOOT.qcow2
-rw-r--r-- 1 root root 120G Feb 19 10:44 DISCO_SECUNDARIO.ovm
[root@odax8godata backup]# qemu-img info DISCO_DE_BOOT.qcow2
image: DISCO_DE_BOOT.qcow2
file format: qcow2
virtual size: 120G (128849018880 bytes)
disk size: 112G
cluster_size: 65536
Format specific information:
compat: 1.1
lazy refcounts: true
refcount bits: 16
corrupt: false
[root@odax8godata backup]# qemu-img info DISCO_SECUNDARIO.ovm
image: DISCO_SECUNDARIO.ovm
file format: raw
virtual size: 120G (128849018880 bytes)
disk size: 120G
[root@odax8godata ~]# cd /u05/app/sharedrepo/ovmstorage/.ACFS/snaps/vm_MVPEP-SML-TRN
[root@odax8godata vm_MVPEP-SML-TRN]# ll -h
total 476M
-rw------- 1 root root 121G Feb 20 02:28 MVPEP-SML-TRN
-rw-r--r-- 1 root root 4.3K Feb 20 02:28 MVPEP-SML-TRN_live.xml
-rw-r--r-- 1 root root 3.7K Feb 20 02:28 MVPEP-SML-TRN.xml
[root@odax8godata ~]# cd /u05/app/sharedrepo/ovmstorage/.ACFS/snaps/vdisk_DISCO_SECUNDARIO
[root@odax8godata vdisk_DISCO_SECUNDARIO]# ll -h
total 120G
-rw-r--r-- 1 qemu qemu 120G Feb 20 02:15 DISCO_SECUNDARIO
Agora vamos substituir os seguintes arquivos…
MVPEP-SML-TRN —>>> DISCO_DE_BOOT.qcow2 DISCO_SECUNDARIO —>>> DISCO_SECUNDARIO.ovm
[root@odax8godata discos_antes_migracao]# cd /backup/
[root@odax8godata backup]# mkdir discos_antes_migracao
[root@odax8godata backup]# mv /u05/app/sharedrepo/ovmstorage/.ACFS/snaps/vm_MVPEP-SML-TRN/MVPEP-SML-TRN /backup/discos_antes_migracao/
[root@odax8godata backup]# mv /u05/app/sharedrepo/ovmstorage/.ACFS/snaps/vdisk_DISCO_SECUNDARIO/DISCO_SECUNDARIO /backup/discos_antes_migracao/
[root@odax8godata backup]# ll -h /backup/discos_antes_migracao/
total 121G
-rw-r--r-- 1 qemu qemu 120G Feb 20 02:15 DISCO_SECUNDARIO
-rw------- 1 root root 121G Feb 20 02:28 MVPEP-SML-TRN
Discos "padrões" movidos, agora vamos colocar no devido lugar o disco de boot convertido e o disco secundário/vdisk que veio do ODA X5/OVM.
root@odax8godata backup]# cd /backup/
[root@odax8godata backup]# ll -h
total 352G
-rw-r--r-- 1 root root 112G Feb 18 19:43 DISCO_DE_BOOT.qcow2
-rw-r--r-- 1 root root 120G Feb 19 10:44 DISCO_SECUNDARIO.ovm
[root@odax8godata backup]# cp DISCO_DE_BOOT.qcow2 /u05/app/sharedrepo/ovmstorage/.ACFS/snaps/vm_MVPEP-SML-TRN/MVPEP-SML-TRN
[root@odax8godata backup]# cp DISCO_SECUNDARIO.ovm /u05/app/sharedrepo/ovmstorage/.ACFS/snaps/vdisk_DISCO_SECUNDARIO/DISCO_SECUNDARIO
[root@odax8godata backup]# ll -h /u05/app/sharedrepo/ovmstorage/.ACFS/snaps/vm_MVPEP-SML-TRN/
total 112G
-rw-r--r-- 1 root root 112G Feb 20 02:52 MVPEP-SML-TRN
-rw-r--r-- 1 root root 4.3K Feb 20 02:28 MVPEP-SML-TRN_live.xml
-rw-r--r-- 1 root root 3.7K Feb 20 02:28 MVPEP-SML-TRN.xml
[root@odax8godata backup]# ll -h /u05/app/sharedrepo/ovmstorage/.ACFS/snaps/vdisk_DISCO_SECUNDARIO/
total 121G
-rw-r--r-- 1 root root 120G Feb 20 02:56 DISCO_SECUNDARIO
[root@odax8godata ~]# cd /u05/app/sharedrepo/ovmstorage/.ACFS/snaps/vm_MVPEP-SML-TRN/
[root@odax8godata vm_MVPEP-SML-TRN]# ll -rths
total 112G
4.0K -rw-r--r-- 1 root root 3.7K Feb 20 02:28 MVPEP-SML-TRN.xml
12K -rw-r--r-- 1 root root 4.3K Feb 20 02:28 MVPEP-SML-TRN_live.xml
112G -rw-r--r-- 1 root root 112G Feb 20 02:52 MVPEP-SML-TRN
[root@odax8godata vm_MVPEP-SML-TRN]# chmod 600 MVPEP-SML-TRN
[root@odax8godata vm_MVPEP-SML-TRN]# ll -rths
total 112G
4.0K -rw-r--r-- 1 root root 3.7K Feb 20 02:28 MVPEP-SML-TRN.xml
12K -rw-r--r-- 1 root root 4.3K Feb 20 02:28 MVPEP-SML-TRN_live.xml
112G -rw------- 1 root root 112G Feb 20 02:52 MVPEP-SML-TRN
[root@odax8godata ~]# cd /u05/app/sharedrepo/ovmstorage/.ACFS/snaps/vdisk_DISCO_SECUNDARIO/
[root@odax8godata vdisk_DISCO_SECUNDARIO]# ll -rths
total 121G
121G -rw-r--r-- 1 root root 120G Feb 20 02:56 DISCO_SECUNDARIO
[root@odax8godata vdisk_DISCO_SECUNDARIO]# chown qemu:qemu DISCO_SECUNDARIO
[root@odax8godata vdisk_DISCO_SECUNDARIO]# ll -rths
total 121G
121G -rw-r--r-- 1 qemu qemu 120G Feb 20 02:56 DISCO_SECUNDARIO
Discos devidamente substituídos, vamos iniciar a VM.
[root@odax8godata vdisk_DISCO_SECUNDARIO]# odacli list-vms
Name VM Storage Node Current State Target State Created Updated
-------------------- -------------------- --------------- --------------- --------------- ----------------------- -----------------------
MVPEP-SML-TRN OVMSTORAGE OFFLINE OFFLINE 2021-02-20 02:28:59 BRT 2021-02-20 02:28:59 BRT
[root@odax8godata vdisk_DISCO_SECUNDARIO]# odacli start-vm -n MVPEP-SML-TRN
Job details
----------------------------------------------------------------
ID: 2d234ec2-df58-44cd-b603-a00b3c972acf
Description: VM MVPEP-SML-TRN start
Status: Success
Created: February 20, 2021 3:07:43 AM BRT
Message:
Task Name Start Time End Time Status
---------------------------------------- ----------------------------------- ----------------------------------- ----------
Validate dependency resources February 20, 2021 3:07:43 AM BRT February 20, 2021 3:07:43 AM BRT Success
Start VM February 20, 2021 3:07:43 AM BRT February 20, 2021 3:07:51 AM BRT Success
Save live VM configuration in ACFS February 20, 2021 3:07:51 AM BRT February 20, 2021 3:07:51 AM BRT Success
Save live VM configuration in metadata February 20, 2021 3:07:51 AM BRT February 20, 2021 3:07:51 AM BRT Success
[root@odax8godata vdisk_DISCO_SECUNDARIO]# odacli list-vms
Name VM Storage Node Current State Target State Created Updated
-------------------- -------------------- --------------- --------------- --------------- ----------------------- -----------------------
MVPEP-SML-TRN OVMSTORAGE odax8godata ONLINE ONLINE 2021-02-20 02:28:59 BRT 2021-02-20 03:07:51 BRT
[root@odax8godata vdisk_DISCO_SECUNDARIO]# odacli describe-vm -n MVPEP-SML-TRN
VM details
--------------------------------------------------------------------------------
ID: f18f916b-19ae-4bfd-af33-f4a49f67f625
Name: MVPEP-SML-TRN
Created: 2021-02-20 02:28:59 BRT
Updated: 2021-02-20 03:07:51 BRT
VM Storage: OVMSTORAGE
Description: NONE
VM size: 120.00 GB
Source: V1003434-01.iso
OS Type: NONE
OS Variant: NONE
Graphics settings: vnc,listen=0.0.0.0
Display Port: :0
Status
--------------------------
Current node: odax8godata
Current state: ONLINE
Target state: ONLINE
Parameters
--------------------------
Preferred node: NONE
Boot option: NONE
Auto start: YES
Fail over: NO
Config Live
------------------------- -------------------------
Memory: 32.00 GB 32.00 GB
Max Memory: 32.00 GB 32.00 GB
vCPU count: 24 24
Max vCPU count: 24 24
CPU Pool: POOL12CORES POOL12CORES
Effective CPU set: 16-27,48-59 16-27,48-59
vCPUs: 0:16-27,48-59 0:16-27,48-59
1:16-27,48-59 1:16-27,48-59
2:16-27,48-59 2:16-27,48-59
3:16-27,48-59 3:16-27,48-59
4:16-27,48-59 4:16-27,48-59
5:16-27,48-59 5:16-27,48-59
6:16-27,48-59 6:16-27,48-59
7:16-27,48-59 7:16-27,48-59
8:16-27,48-59 8:16-27,48-59
9:16-27,48-59 9:16-27,48-59
10:16-27,48-59 10:16-27,48-59
11:16-27,48-59 11:16-27,48-59
12:16-27,48-59 12:16-27,48-59
13:16-27,48-59 13:16-27,48-59
14:16-27,48-59 14:16-27,48-59
15:16-27,48-59 15:16-27,48-59
16:16-27,48-59 16:16-27,48-59
17:16-27,48-59 17:16-27,48-59
18:16-27,48-59 18:16-27,48-59
19:16-27,48-59 19:16-27,48-59
20:16-27,48-59 20:16-27,48-59
21:16-27,48-59 21:16-27,48-59
22:16-27,48-59 22:16-27,48-59
23:16-27,48-59 23:16-27,48-59
vDisks: DISCO_SECUNDARIO:vdb DISCO_SECUNDARIO:vdb
vNetworks: VNET1:52:54:00:68:26:a9 VNET1:52:54:00:68:26:a9
